4Pcs Ignition Coils Pack
for Toyota Prius Corolla Matrix Lexus CT200H Pontiac Vibe 1.8L
Replaces OE: 90919-02258 90919-02252
$69.95
COPY
5% OFF
OFFER5
✔ Copied
Standard
Calculating...
Free
-
Fast Free Shipping›
-
2-Year Warranty›
-
30-Day Free Returns›
-
24/7 Customer Service›
-
Guaranteed Exact Fit›
Check if this fits your vehicle
Close
! ! !
Out of stock in local warehouse
Requires shipment from overseas warehouse
Longer shipping time
Please do not place orders if this is a concern
！！！
Out of stock in local warehouse
Requires shipment from overseas warehouse
Longer shipping time
Please do not place orders if this is a concern
Automotive-Leader Ignition coil
Vehicle Compatible
|
Year
|
Make
|
Model
|
Engine/Displacement
|
|---|---|---|---|
|
2011-2017
|
Lexus
|
CT200h
|
-
|
|
2009-2010
|
Pontiac
|
Vibe
|
1.8L
|
|
2016
|
Scion
|
iM
|
-
|
|
2008-2014
|
Scion
|
xD
|
-
|
|
2009-2017
|
Toyota
|
Corolla
|
1.8L
|
|
2017
|
Toyota
|
Corolla (iM)
|
-
|
|
2009-2013
|
Toyota
|
Matrix
|
1.8L
|
|
2010-2016
|
Toyota
|
Prius
|
1.8L
|
|
2012-2015
|
Toyota
|
Prius Plug-In
|
-
|
|
2012-2017
|
Toyota
|
Prius V
|
-
|
Product Specifications
Warranty & Support: 2 Years + Pre-sale Load Test + 24/7 Technical Support
|
Item
|
Specification
|
|---|---|
|
Core Part Number
|
UF-596
Interchange: UF-619, 90919-02252, 90919-02258, 673-1310, C1714, 5C1771, E1096, IC686, IC722, 52-2126, GN10341 |
|
Position
|
Engine, Coil On Plug (COP)
|
|
Key Parameters
|
- System Voltage: 12V
- Overall Height: 6-3/4 in - Connector/Terminal: Male, 4-pin Blade Type - Mount Type: Bolt On - Ignition Type: Electronic (COP Configuration) - Finish: Black, Silver, Gray - Material: Plastic Housing - Performance: 10% stronger power, 0.5s fast ignition - Efficiency: 15% energy saving - Durability: 50,000 km service life; High-temperature & corrosion resistant materials |
Package Content:
Pack Of 4Pcs 90919-02258 Ignition Coil
How to install the ignition coil ？
Step 1 - Remove the fuel rails by simply unbolting the two bolts on the top, then gently pulling it up.
Step 2 - Remove the bolts/connectors from the ignition coil in a numerical order.
Step 3 - Repeat this step for each coil.
Step 4 - Best to replace the entire coil pack as opposed to just one coil in order to avoid malfunctions in the future. The coils should snap into place.
Step 5 - The coil bolts should be precisely tightened to 50 inch pounds.
Step 6 - Using the palm of your hand, snap the fuel rail back into place and tighten the bolts around it.
Please check the fitment notes for Oxygen sensor installation location information！！！
Bank 1 Sensor 1 means Upstream Right/Rear; Bank 2 Sensor 1 means Upstream Left/Front
Bank 1 Sensor 2 means Downstream Right/Rear; Bank 2 Sensor 2 means Downstream Left/Front
sensor 1=Upstream sensor 2=Downstream
